For the modern science lab. Working with up to 4 sensors at a time, it will show readings on its bright clear screen as a meter display or, at the touch of a button, it will record them into its built in datalogger memory and display them as a graph.

Main features include:

• One touch logging - easy to use


• Over 50 Microsense® sensors and adapters available


• Super low power - 2 x standard AA Alkaline batteries will last for months – so always ready to use


• Timing options built in: Time, Speed, Acceleration and SHM. Supports Picket fence, Double and Single interrupt cards


• (High resolution - better than 1µs!)


• Splashproof face keeps it safe from lab spills or rain showers


• Stores up to 8000 readings per sensor per experiment - 256,000 readings


• Logs for more than 250 days!


• USB port for wired connection and powering from a PC or Mac


• Smart low energy bluetooth wireless built in for any iPad Mini or iPad 3 and above


• Software for iPad, Windows & Mac included

Meter Logging

• Autolog – just press “Start” to start logging and “Stop” to stop


• Set Log Rate – set the experiment duration and sample rate


• Snapshot – store the sensor readings every time the “Store” button is pressed


• Triggered – starts logging when an event happens, such as dropping a magnet through a coil

Recommended accessories

• Light Level D100159


• Temperature D100047


• Sound Level D100060

Timing

Using either Single, Double or Picket Fence interrupt cards

• Time at A


• Time at A and B


• Time from A to B


• Time at A, from A to B, and B


• Speed at A


• Speed at A and B


• Speed from A to B


• Acceleration at A


• Simple Harmonic Motion


• Stopwatch / Timer

Recommended accessories

• Light Gate Set D100054 contents

2 x Light Gate Vision, with visible light beam
2 x Mounting rod 120mm x 10mm diameter
2 x Mounting Screws

• Timing card set D101130 contents

1 x single,
1 x double
1 x picket fence

• Pressure Mat Set D100094 contents

2 x Pressure mat's

 Oscilloscope

• 1 or 2 Channel


• Time base 20us to 100ms / Div


• Y scale auto zooms to make full use of the display


• Hold and Save waveform


• ADC 12 bit resolution


• Auto triggers to waveform

Recommended accessories

• Sound Wave x 2 D100060


• Light Level D100159 Smart Eye sensor


• Voltage measurement set D100045 (+/- 25v lead, 15 piece test lead set)


• +/- 1250mv (Redox adapter) D100139


• Pulse Monitor D100092

Technical

• Power - 2 x AA or USB when connected


• Display - low power backlit 128 x 64 monochrome LCD, designed for indoor and outdoor use


• Connectivity – USB and Low power Bluetooth


• Sensor Socket – 4 x microsense
